12V 5A Power Adapter SMPS

The 12V 5A Power Supply is a compact and reliable power source designed to provide a stable 12V output with a maximum current of 5A. It is suitable for a variety of applications, including powering CCTV cameras, LED lighting systems, small electronics projects, and other devices that require a steady 12V DC supply. The power supply features over-voltage, over-current, and short-circuit protection to ensure the safety and longevity of connected devices. Key Features:

• Output Voltage: 12V DC
• Output Current: 5A
• Power Output: 60W
• Input Voltage: 100-240V AC, 50/60Hz
• Connector Type: Screw terminals or DC barrel jack
• Protection: Over-voltage, over-current, and short-circuit protection
• Efficiency: High efficiency for consistent power delivery
• Cooling: Built-in cooling or heat dissipation mechanism
• Certifications: CE, FCC, RoHS compliant

Technical Specifications:

• Output Voltage: 12V DC ± 5%
• Output Current: 5A
• Power Output: 60W
• Input Voltage: 100-240V AC, 50/60Hz
• Ripple & Noise: ≤ 150mV
• Load Regulation: ± 1%
• Line Regulation: ± 1%
• Operating Temperature: -10°C to +60°C
• Storage Temperature: -20°C to +85°C
• Humidity: 0% to 95% non-condensing
• Dimensions: Approx. 150mm x 70mm x 40mm
• Weight: 300 g
• Connector Type: Screw terminals or 5.5mm x 2.1mm DC barrel jack
• Cooling: Passive cooling or built-in fan (depending on model)
